Sany STC800E5, 4-axle, 5-section boom truck crane from the year 2020, with over 30,000 kilometers of travel and more than 10,000 hours of working time. The vehicle has undergone strict inspection and it is confirmed that there are no cracks or reinforcements on the structural components. We look forward to your inquiry!

Main boom: 50.5 meters,

Jib: 17.5 meters,

Counterweight: 20 tons,

Hooks: 50T, 7.5T,

Engine: WP12375E50,

Transmission: Fast Gear 12-speed transmission,

Wechat: 17570011677

Whatsapp: 008617570011677

The Sany STC800E5 truck crane in 2020 has the following product advantages:Outstanding Lifting Performance• Powerful Lifting Capacity:The maximum lifting capacity reaches 80 tons,with a maximum lifting height of 77 meters.The main boom has a full extension length of 50 meters,and it is equipped with a 17.5-meter auxiliary boom and a 9.5-meter extension boom.The maximum lifting moment of the basic boom is 3410.4 kN·m.• Efficient Boom Extension:The main boom uses a double-cylinder rope arrangement mechanism.The full extension time of the main boom is 125 seconds,which is more efficient than the single-cylinder pinning mechanism.• Precision Lifting Capability:Equipped with an imported main oil pump and double-plunger pump,the minimum stable rotation speed is 0.15°/s,and the minimum stable hoisting speed is 1.5 m/min,which can meet the needs of precision lifting.Strong Power and Chassis• Powerful Power System:It uses a Weichai WP12 series high-torque engine with a maximum power of 294 kW/1900 rpm and a maximum output torque of 2000 N·m/(1000–1400)rpm.It is equipped with a 10-speed transmission with synchronizers,with a maximum speed of up to 90 km/h and a maximum climbing gradient of 45%.• Upgraded Chassis Design:The position of the air reservoir has been optimized,and the chassis has been upgraded to the G-class.The approach angle and departure angle are larger,allowing it to adapt to various harsh road conditions.Good Operation and Control• Intelligent Flow Distribution System:Equipped with a new dual-pump intelligent flow distribution system,the boom can operate independently,and the extension can be combined.The controllability of compound actions has been improved by more than 50%.• Humanized Operator's Cabin Design:The operator's cabin can be tilted at 0–20°and is wider,making high-altitude operations more comfortable and safer.The cabin is equipped with a new three-dimensional 7-channel air conditioning system,front air conditioning buttons,new film switch buttons,a mobile phone holder,and a cup holder.Low Operating Costs• Energy-saving Hydraulic System:Equipped with a new liquid-electric control system,it can adjust the pump displacement in real time to achieve high-precision flow control and greatly reduce energy loss,saving more than 10%of operating costs.• Convenient Transportation Capability:The large-tonnage dedicated rear balance suspension is used,which is highly reliable and capable of carrying the active counterweight for transportation.For short-distance transportation,there is no need to unload the counterweight,saving time and effort.High Cost-effectiveness• High-Quality Core Components:All core hydraulic components are from imported brands,ensuring the reliability and durability of the equipment.• Multi-functionality and Flexibility:Equipped with a variety of lifting tools and accessories,such as scissor clamps,log clamps,and lifting hooks,which can meet different lifting needs.
